ALIMENTATORE ATX ASUS TUF-GAMING-1000G-EVO 80+ GOLD 1000W FULLY MODULAR ROHS MILITARY GRADE 90YE00SE-B0NA00

Modello
TUF Gaming 750W Gold

Intel Form Factor
ATX12V

PFC Type
Active PFC

ATX Standard
ATX 3.1

Dimensioni
150 x 150 x 86 mm

Efficienza
80Plus Gold

MTBF
>120,000 hrs @ 40°C

Caratteristiche di protezione
OPP/OVP/SCP/OCP/OTP

Materiali pericolosi
ROHS

Input Range AC
100-240Vac

Uscita voltaggio DC
+3.3V +5V +12V -12V +5Vsb

Carico massimo
25A25A62A 0.8A 3A

Combined Load
130W 130W 744W 9.6W 15W

Uscita totale
750W

Connettori
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 16-pin x 1 (both PSU & component side)
PCI-E 8-pin x 3
SATA x 5
PERIPHERAL x 4

Contenuto della confezione
Power Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable x 2 (650mm)
PCI-E Gen 5.1 16-pin Cable x 1 (675mm)
PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (675mm)
PCI-E 1-to-1 Cable x 1 (675mm)
SATA 1-to-2 Cable x 1 (400+120mm)
SATA 1-to-3 Cable x 1 (400+120+120mm)
Peripheral 1-to-4 Cable x 1 (400+150+150+150mm)
TUF Gaming Cable Tie x 3
User Manual x 1

Weight
2.38kg (single PSU)

0dB Technology
Supported. The fan shuts off entirely when the PSU is under certain load

0dB Fan Button
No. The product operates in 0dB mode by default. The fan will only spin up when the system reaches a certain load.
